ATI
ATI611 Compact Offset Aircraft Rivet Bucking Bar
ATI611 Compact Offset Aircraft Rivet Bucking Bar
NSN: 5120-01-368-4354
Out of stock. Call for shipping times.
Couldn't load pickup availability
The ATI611 is a compact, precision-engineered aircraft rivet bucking bar forged from high-density, heat-treated alloy steel. Weighing 1.10 lbs, it is designed with specialized offset angle faces to allow mechanics to buck solid rivets around internal obstruction lips, stringer flanges, and tight structural bulkheads.
Tool Type: Airframe Rivet Bucking Bar
Weight: 1.10 lbs (0.50 kg)
Material: Precision-machined, heat-treated alloy tool steel for high mass-to-volume ratio
Surface Finish: Polished working faces (minimum 63 micro-inch finish) with smooth radiused corners to prevent skin indentations and stress marks
Application: Ideal for backing solid aluminum rivets (-03, -04, and -05 dash sizes) in tight-clearance skin lap joints, frame channels, and internal wing rib assemblies
