ATI518C (Two-Lug Double Wing Standard Nut Plate Drill Jig, #10 Screw Size)
ATI518C (Two-Lug Double Wing Standard Nut Plate Drill Jig, #10 Screw Size)
Out of stock. Call for shipping times.
Couldn't load pickup availability
The ATI518C is a standard-size double-wing sheet metal drill jig designed to locate and accurately drill rivet mounting holes when installing two-lug standard anchor nuts (nut plates) on airframe structures.
Key features and specifications:
Screw/Pilot Size: #10 (0.191" pilot diameter)
Rivet Hole Drill Size: #40 (0.098")
Rivet Hole Spacing: 0.344" (center to center per side) / 0.688" total wing span
Construction: Built with a hardened O-1 tool steel drill bushing block connected via a flexible stainless spring-steel strap to a knurled handle, allowing hand clearance and flexibility in tight structural areas.
